TRENDnet TPE-082WS 10-Port Gigabit PoE+ Managed Switch

TRENDnet TPE-082WS 10-Port Gigabit PoE+ Managed Switch

Name: TRENDnet TPE-082WS 10-Port Gigabit PoE+ Managed Switch
Brand: TRENDnet
SKU: BH1359229
Availability: InStock

$90.99

10-Port Gigabit PoE+ Managed Switch with 20Gbps capacity, 8x PoE ports, and advanced management features for network control.

In stock

SKU: BH1359229 Category: Wired Networking Brand: TRENDnet

Description

TRENDnet TPE-082WS: Advanced Network Management

The TRENDnet TPE-082WS 10-Port Gigabit PoE+ Managed Switch offers comprehensive network control with its 20 Gbps switching capacity and advanced management features. Ideal for network administrators seeking flexibility and reliability.

Key Features

10 Gigabit ports (8x RJ45, 2x SFP slots)
75W PoE power budget with up to 30W per port
Advanced management features: 802.3ad link aggregation, 802.1Q VLAN, Voice VLAN
Monitoring protocols: RMON, SNMP, SNMP Trap, Port Mirroring
Access control: ACL, SSL, MAC/port filtering
Fanless metal housing for rack installation

This switch is designed to simplify network management and enhance performance. With its robust feature set, it supports a wide range of applications, from powering access points and IP cameras to managing complex network infrastructures.

Benefits

The TPE-082WS offers numerous benefits, including improved network reliability, enhanced security through advanced access control, and simplified management through comprehensive monitoring protocols. Its PoE capabilities allow for the easy installation of devices without the need for additional power sources, making it an ideal solution for modern network environments.

By integrating the TPE-082WS into your network, you can ensure a robust, scalable, and manageable infrastructure that meets your current and future needs.

Additional information

Weight	4.6 lbs
Dimensions	13.1 × 11.3 × 3 in
Standards	IEEE 802.1d<br> IEEE 802.1p<br> IEEE 802.1Q<br> IEEE 802.1s<br> IEEE 802.1w<br> IEEE 802.1X<br> IEEE 802.1ab<br> IEEE 802.3<br> IEEE 802.3u<br> IEEE 802.3x<br> IEEE 802.3z<br> IEEE 802.3ab<br> IEEE 802.3ad<br> IEEE 802.3af<br> IEEE 802.3at<br> IEEE 802.3az
Multicast	IGMP Snooping v1, v2, v3 (per VLAN)<br> Static Multicast Address<br> Up to 256 multicast entries
Temperature & Humidity	Operating Temperature<br> 23 to 122°F / -5 to 50°C<br> Operating Humidity<br> Max. 95% non-condensing
MTBF	862, 966 hours
Power	Input: 100 – 240 VAC, 50/60 Hz, internal power supply<br> Consumption: 82 W (max.)<br> Power Budget: 75 W
Compatibility	Optional Software Utility: Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server
ACL	ACL IPv4 L2-L4 & IPv6<br> MAC Address<br> VLAN ID<br> Ether Type (IPv4 only)<br> IP Protocol 0-255<br> TCP/UDP Port 1-65535<br> 802.1p<br> DSCP (IPv4 only)<br> IPv6 Address (IPv6 only)
Encryption	802.1X Port-Based Network Access Control, RADIUS, TACACS+<br> Local Dial-In User Authentication<br> DHCP Snooping (per VLAN)<br> Loopback Detection<br> Duplicated Address Detection<br> Trusted Host<br> Denial of Service (DoS)
Port Mirroring	RX, TX, or Both<br> One to one
VLAN	Multiple management VLAN assignment<br> Asymmetric VLAN<br> 802.1Q Tagged VLAN<br> Dynamic GVRP<br> Up to 256 VLAN groups, ID Range 1-4094<br> Private VLAN (Protected Ports)<br> Voice VLAN (10 user defined OUIs)
Device Interface	8 x Gigabit PoE+ ports<br> 2 x SFP slots<br> LED indicators
Quality of Service (QoS)	802.1p Class of Service (CoS)<br> DSCP (Differentiated Services Code Point)<br> Bandwidth Control per port<br> Queue Scheduling: Strict Priority, Weighted Round Robin (WRR)
Link Aggregation	Static Link Aggregation<br> 802.3ad Dynamic LACP
Spanning Tree	IEEE 802.1D STP (Spanning Tree protocol)<br> IEEE 802.1w RSTP (Rapid Spanning Tree protocol)<br> IEEE 802.1s MSTP (Multiple Spanning Tree protocol)
MIB	IP FORWARD TABLE MIB RFC 1354<br> RMON MIB RFC 1271<br> IPV4 MIB RFC 1213<br> IPV6 MIB RFC 2465<br> GVRP MIB IEEE 802.1Q-VLAN<br> LA MIB IEEE 802.3ad<br> LLDP MIB IEEE 802.1AB<br> IGMP SNOOPING MIB RFC 2933<br> MLD SNOOPING MIB RFC 3019v PRIVATE VLAN MIB IEEE 802.1Q<br> DHCPSNOOP MIB RFC 2026<br> QOS MIB RFC 4323<br> SNMP MIB RFC 3415<br> STP MIB RFC 4318<br> PNAC MIB IEEE 802.1x<br> VLAN MIB IEEE 802.1q<br> DNS MIB RFC 1611<br> ACL MIB<br> BANDWIDTH CTRL MIB<br> LBD MIB<br> MIRROR MIB<br> IPV6 NEIGHBOR MIB<br> SNTP MIB<br> STORM CTRL MIB<br> STATISTICS MIB<br> Tool MIB<br> VOICE VLAN MIB<br> DOS MIB
Management	HTTP/HTTPS (SSL v2/3 TLS) Web based GUI<br> SNMP v1, v2c, v3<br> RMON v1<br> Static Unicast MAC Address<br> Enable/disable 802.3az Power Saving<br> LLDP and LLDP-MED<br> Virtual Cable Diagnostics Test<br> IPv6: IPv6 Neighbor Discovery, IPv6 Static IP, DHCPv6, Auto configuration
Performance	Switch fabric: 20 Gbps<br> RAM buffer: 512 KB<br> MAC Address Table: 8 K entries<br> Jumbo Frames: 10 KB<br> HOL Blocking Prevention<br> Forwarding Rate: 14.9 Mpps (64-byte packet size)
Data Transfer Rate	Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)<br> Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)<br> Gigabit Ethernet: 2000 Mbps (full duplex)
Certifications	CE, FCC
